900 Hz to 120 GHz Keysight PNA vector network analyzer

Keysight Technologies presented a broadband millimeter-wave network analyzer solution that delivers unparalleled system-level accuracy up to 120 GHz. The new Keysight N5290/91A solutions produce metrology-grade results that enable leading-edge developers to confidently characterize their millimeter-wave designs.

The new solution enhances device characterization and modeling by delivering exceptional stability and accuracy for on-wafer and connectorized measurements. Magnitude stability is less than 0.015 dB and phase accuracy is less than 0.15 degrees over a 24-hour period.

Leveraging Keysight's proven expertise in metrology, the solution's calibration capabilities are based on an improved-accuracy database that supports a 1.0 mm calibration kit (85059B) and a 1.0 mm verification kit (85059V). With this foundation, the new broadband millimeter-wave solution provides measurement results that are traceable to national metrology institutes.

Core elements of the system are a Keysight PNA or PNA-X network analyzer, along with N5293A Series compact frequency extenders and the N5292A test-set controller. To simplify benchtop measurements, engineers can mount the frequency extenders on an optional desktop positioner.

Ruggedized 1.0 mm test ports ensure repeatable connections that improve calibration uncertainty and therefore system-level measurement precision. Users can apply automatic fixture de-embedding to connectorized measurements or perform calibration at the probe tips during on-wafer measurements.
