New 3-phase AC power supplies Keysight AC6900

Keysight Technologies has introduced a new family of 3-phase AC power supplies AC6900, which complements 1-phase AC power supplies families AC6800B and 6800C. New power supplies are available in 4 power ranges 3, 6, 12 and 18 kVA. If you need even higher power, you can connect in parallel up to 4 units and get the power supply with total power of up to 72 kVA. Maximum output frequency of AC signal is 5 kHz (H models) or 550 Hz (L models).

Main features:

Output:

  • Single-phase or three-phase
  • AC, DC, or AC plus DC mode
  • maximum AC voltage at 320 Vrms
  • maximum DC voltage at 452 V
  • frequency up to 5 kHz

Precision measurements:

  • AC, DC, AC plus DC voltage, and current
  • peak voltage and current
  • real, apparent, and reactive power; crest factor and power factor
  • harmonic analysis of voltage and current waveforms providing amplitude and phase up to the 50th harmonic
  • total harmonic distortion (THD)

Built-in tests:

  • power line disturbance
  • sequencing
  • built-in waveform generation

Programming and remote control:

  • analog and digital control
  • LAN eXtensions, USB, and GPIB
  • PathWave BenchVue AC source & AC source avionics standard test software

More information about new 3-phase AC power supplies Keysight AC6900 can be found in  data sheet.
